D x x x
A x x x
X x x x
X P x x
s x x x
4. Programming
4-7
Function Display Description Default Range Unit
4-6. Advanced block parameters -ADV-
Lock-out
E2PROM reading
Factory settings
Undervoltage
Undervoltage trip time
Overvoltage
Overvoltage trip time
Undercurrent
Undercurrent trip time
Overcurrent
Overcurrent trip time
Dual Ramp Up
Dual Ramp Down
Dual StartingTorque
L K x x
R x x x
Q x x x
U V x x
u v x x
O V x x
o v x x
U C x x
u c x x
O C x x
o c x x
2 a x x
2 d x x
2 T x x
L K 0 5
R O F F
Q O F F
U V 0 0
u v 2 0
O V 0 0
o v 2 0
U C 0 0
u c 2 0
O C 0 0
o c 2 0
2 a 1 5
2 d 2 0
2 T 2 5
Sets time between consecutive starts. Setting "0" disables
this function.
Loads the parameters from the E2PROM to the temporal
buffer.
Loads default factory settings to the temporal buffer.
Resave to E2PROM if default settings are desired.
The unit trips if the line voltage on Leg L1 decreases below
the percentage set. Setting “0” disables this protection.
NOTE:
Perform voltage calibration procedure on page
4-5 before enabling this protection.
Delay trip time.
The unit trips if the line voltage on Leg L1 increases above
the percentage set. Setting “0” disables this protection.
NOTE:
Perform voltage calibration procedure on page
4-5 before enabling this protection.
Delay trip time.
The unit trips if the current decreases below the percentage
set. Setting “0” disables this protection.
NOTE:
Perform current calibration procedure on page
4-5 before enabling this protection.
Delay trip time.
The unit trips if the current increases above the percentage
set. Setting “0” disables this protection.
NOTE:
Perform current calibration procedure on page
4-5 before enabling this protection.
Delay trip time.
These are a secondary set of ramp up, ramp down and
starting torque parameters, which take over the primary "a",
"d" and "T" when the programmable function “A” is enabled.
00-45
ON, OFF
ON, OFF
00-50
00-99
00-30
00-99
00-99
00-99
00-50
00-99
01-45
01-60
10-90
min.
-
-
%
sec.
%
sec.
%
sec.
%
sec.
%
%
%
4-6-1. Advanced functions
Function Display Description Default Range
4-6-2. Programmable advanced functions
Linear ramp
Dual motor selector
Remote control selector
Comunication protocol
Station number
D O F F
A O F F
X O F F
X P 0 0
s 0 0 1
This function provides linear acceleration and deceleration ramps in a
wider range of load conditions using tachogenerator feedback.
A DC Tacho-Generator coupled to motor must be used to provide an
analog signal feedback of 0-5VDC to terminals 7 and 8.
This function allows dual motor control settings of acceleration,
deceleration and starting torque, and is useful to start or stop a motor
in diferent load conditions.
When this function is enabled, the parameters 2a, 2d and 2T take over
the parameters a, d and T. It allows dual motor control settings.
Allows serial communication control by SG, TD and RD terminals.
Check Appendix section for more details.
Sets serial communications protocol.
0: ASCII
1: Future use
2: Future use
ASCII protocol allows a maximum of 90 stations only.
OFF, ON, I3, I4
OFF, ON, I3, I4
OFF, ON, I3, I4
00-02
001-247
