MULTIPULSE DRIVE PANEL
32 GE Energy ©2012 GE Company All Rights Reserved
Table 9-7
GE Drive Unit size Drive Terminal Torque (lb. in.) Torque (Nm)
Bolt
Size
12, 13, 23
Line In 16 1.8 NA
Motor 16 1.8 NA
DC Connection 16 1.8 NA
Brake 16 1.8 NA
Earth 27 3 NA
Relay 5 0.6 NA
24
Line In 40 4.5 NA
Motor 40 4.5 NA
DC Connection 40 4.5 NA
Brake 40 4.5 NA
Earth 27 3 NA
Relay 5 0.6 NA
33
Line In 89 10 NA
Motor 89 10 NA
DC Connection 89 10 NA
Brake 89 10 NA
Earth 27 3 NA
Relay 5 0.6 NA
34
Line In
124 ( < AWG 4/0) /
212 (> AWG 4/0)
14 (<95 sq.mm.) /
24(> 95 sq. mm.) NA
Motor
124 ( < AWG 4/0) /
212 (> AWG 4/0)
14 (<95 sq.mm.) /
24(> 95 sq. mm.) NA
DC Connection 124 14 NA
Brake 124 14 NA
Earth 27 3 NA
Relay 5 0.6 NA
41, 42 ,43, 44
Mains
168 19 M10
Motor
Load Sharing
84 9.5 M8
Brake
51, 52
Mains
168 19 M10 Motor
Load Sharing
Brake 84 9.5 M8
61, 62, 63, 64
Mains
168 19 M10
Motor
Load Sharing 168 19 M10
Brake 84 9.5 M8
Regen 168 19 M10
