MULTIPULSE DRIVE PANEL
28 GE Energy ©2012 GE Company All Rights Reserved
Table 9-3
Ferraz
Shawmut -
Fusible
Disconnect
Wire Range
AWG
Wire
Tightening
Torque (lb.
In.)
FBJ30U # 3 - # 10 (1) 58
FBJ60U # 3 - # 10 (1) 58
FBJ100U 2 / 0 - # 14 (1) 120
FBJ200U 3 / 0 - # 6 (1) 200
FBJ400U
600 kcmil - #2
(1)
500
FBJ600U
600 kcmil - #2
(2)
500
FBL800U
600 kcmil - #2
(2)
500
Table 9-4
GE Spectra Circuit
Breaker
Wire Range
Wire Tightening Torque
(lb. in.)
# 12 - # 3/0 Cu.
# 12 - # 3/0 Al.
# 12 - # 10 --------- 35
SELA36AI0150 # 8 - # 3 ------------- 100
# 2 - # 3/0 ---------- 150
# 8 - 350 kcmil Cu.
# 8 - 350 kcmil Al.
# 8 - # 4 ------------- 150
SFLA36AI0250 # 3 - # 1 -------------- 200
1/0 - 350 kcmil ----- 275
SGLA36AI0400
Wire Top
# 8 - 500 kcmil Cu.
# 8 - 500 kcmil Al.
Wire Bottom
2/0 - 600 kcmil Cu.
2/0 - 600 kcmil Al.
# 8 - # 3 ------------ 275
SGLA36AI0600 # 2 - 600 kcmil --- 375
SKLA36AI0800
3/0 - 500 kcmil Cu.
3/0 - 500 kcmil Al.
375
SKLA36AI1200
250 - 500 kcmil Cu.
250 - 500 kcmil Al.
375
