MULTIPULSE DRIVE PANEL
23 GE Energy ©2012 GE Company All Rights Reserved
Table 7.2
460 VAC Panel Current Ratings and
Maximum Allowable Fuse Sizes
Panel HP
Rating
Panel Current
Rating (Amps)
Maximum
Allowable Fuse
Size (Amps)
1 2.1 3.7
2 3.4 6.0
3 4.8 8.4
5 8.2 13.3
7.5 11 19.3
10 14.5 24.5
15 21 36.8
20 27 47.3
25 34 59.5
30 40 70.0
40 52 91.0
50 65 113.8
60 80 134.8
75 105 168.0
100 130 217.0
125 160 273.0
150 190 320.3
200 240 420.0
250 302 528.5
300 361 631.8
350 443 763.0
450 540 929.3
500 590 1032.5
550 678 1167.3
600 730 1256.5
650 780 1352.8
750 890 1541.8
900 1050 1828.8
1000 1160 2009.0
1200 1380 2409.8
1350 1530 2649.5
