GE Industrial Solutions AF-650 GP MultiPulse Drive Panel - Manual (Page 27)

MULTIPULSE DRIVE PANEL
27 GE Energy ©2012 GE Company All Rights Reserved
9 Appendix B – Wire Sizes and Torque Details
Table 9-1
GE IEC 2000
Power
Contactors
Wire Range
Wire
Tightening
Torque
(In.lb)
CL00 14-10 15
CL01 14-10 15
CL02 14-10 15
CL25 14-8 20
CL04 14-8 16
CL45 14-8 16
CL06 14-1/0 50
CL07 14-1/0 50
CL08 14-1/0 50
CL09 10-1/0 60
CL10 10-1/0 60
CK75 #6-250 MCM 275
CK08 #6-250 MCM 275
CK09 #6-350 MCM 200
CK95 #6-350 MCM 200
CK10
#8-500 MCM,
2/0-600MCM
375
CK11
#8-500 MCM,
2/0-600MCM
375
CK12
#8-500 MCM,
2/0-600MCM
375
Table 9-2
Ferraz
Shawmut Non
Fusible
Disconnect
Wire Range
AWG
Wire
Tightening
Torque (lb.
In.)
SCV30U # 10 - # 14 (1) 27
SCV60U # 3 - # 10 (1) 58
SCV100U # 3 - # 10 (1) 58
SCV200U 3 / 0 - # 6 (1) 200
SCV400U
600 kcmil - #2
(1)
500
SC600
600 kcmil - #2
(2)
500
SC800
600 kcmil - #2
(3)
500
