MULTIPULSE DRIVE PANEL
24 GE Energy ©2012 GE Company All Rights Reserved
Table 7.3
575 VAC Panel Current Ratings and
Maximum Allowable Fuse Sizes
Panel HP
Rating
Panel Current
Rating (Amps)
Maximum
Allowable Fuse
Size (Amps)
1 1.8 4.2
2 2.7 4.7
3 3.9 7.2
5 6.1 10.7
7.5 9 15.8
10 11 19.3
15 18 30.1
20 22 38.5
25 27 47.3
30 34 57.2
40 41 71.8
50 52 91.0
60 62 108.5
75 83 138.1
100 100 173.3
125 131 218.8
150 155 264.3
200 192 336.0
250 242 423.5
300 290 505.8
350 344 593.3
400 410 691.3
450 450 759.5
500 500 843.5
600 570 994.0
650 630 1076.3
750 730 1267.0
950 850 1477.0
1050 945 1650.3
1150 1060 1849.8
1350 1260 2198.0
