GE Industrial Solutions AF-650 GP MultiPulse Drive Panel User Manual
Page 29
MULTIPULSE DRIVE PANEL
29 GE Energy ©2012 GE Company All Rights Reserved
Table 9-5
Table 9-6
Voltage
Rating in
(VAC)
HP
Rating
AF-600 FP
(Drive
Terminal
Cable Size)
AF-650 GP
(Drive
Terminal
Cable Size)
AF-600
FP Unit
size
AF-650
GP Unit
Size
208
1
10
10
12
12
208
2
10
10
12
12
208
3
10
10
12
12
208
5
10
10
13
13
208
7.5
6
6
23
23
208
10
6
6
23
23
208
15
6
6
23
24
208
20
2
2
24
24
208
25
1/0
1/0
33
33
208
30
1/0
1/0
33
33
208
40
1/0
1/0
33
34
208
50
4/0
4/0
34
34
208
60
250 MCM
--
34
-
460
1
10
10
12
12
460
2
10
10
12
12
460
3
10
10
12
12
460
5
10
10
12
12
460
7.5
10
10
13
13
460
10
10
10
13
13
460
15
6
6
23
23
460
20
6
6
23
23
460
25
6
2
23
24
460
30
2
2
24
24
GE IEC 2000 series
Overload Relay
Wire Range
Wire
Tightening
Torque (lb.
in.)
RT1
# 14 - # 8
14 - 20
RT2A - J
# 10 - # 3
50
RT2K - M
# 10 - # 1
50
RT3
# 6 - 250 kcmil
275
RT4
# 6 - 350 kcmil
200
RT5
# 8 - 500 kcmil
# 2/0 - 600 kcmil
375
RT4L
# 6 - 350 kcmil
200
RT5L
# 8 - 500 kcmil
# 2/0 - 600 kcmil
375
