MULTIPULSE DRIVE PANEL
31 GE Energy ©2012 GE Company All Rights Reserved
(Table 9-6 continued)
Voltage
Rating in
(VAC)
HP
Rating
AF-600 FP
(Drive
Terminal
Cable Size)
AF-650 GP
(Drive
Terminal
Cable Size)
AF-600
FP Unit
size
AF-650
GP Unit
Size
575 125 250 MCM 2x2/0 34 43
575 150 2x2/0 2x2/0 43 43
575 200 2x2/0 2x350 MCM 43 44
575 250 2x350 MCM 2x350 MCM 44 44
575 300 2x350 MCM 2x350 MCM 44 44
575 350 2x350 MCM 2x350 MCM 44 44
575 400 2x350 MCM 4x500 MCM 44 52
575 450 4x500 MCM - 52 -
575 500 4x500 MCM 4x500 MCM 52 52
575 600 4x500 MCM 4x500 MCM 52 52
575 650 4x500 MCM 8x300 MCM 52 61
575 750 8x300 MCM 8x300 MCM 61 61
575 950 8x300 MCM 8x300 MCM 61 61
575 1050 8x300 MCM 12x300 MCM 61 62
575 1150 12x300 MCM 12x300 MCM 62 62
575 1350 12x300 MCM - 62 -
