Renewal Parts List For ASTAT-CD Plus Solid-State Starters
GE Industrial Systems
General Electric Company
41 Woodford Ave., Plainville, CT 06062
www.GEindustrial.com
© 2001 General Electric Company
DEH-40418 0901
Description Where Used Cat. No.
List Price (Each), Required
GO-11G Qty.
SCR, 1 per phase QC2FDP QCX000111 $55.00 1
QC2GDP QCX000112 60.00 1
QC2HDP QCX000113 65.00 1
QC2IDP QCX000114 70.00 1
QC2JDP QCX000115 80.00 1
QC2KDP QCX000116 160.00 1
QC2LDP QCX000117 300.00 1
QC2MDP QCX000118 350.00 1
SCR, 2 per phase QC2NDP QCX000119 270.00 2
QC2QDP QCX000120 320.00 2
QC2RDP QCX000121 500.00 2
QC2SDP QCX000122 515.00 2
QC2TDP QCX000123 652.00 2
QC2UDP QCX000124 733.00 2
QC2VDP QCX000125 1,040.00 2
QC2XDP QCX000126 1,250.00 2
Protection Circuit Board QC2FDP QCX000127 120.00 1
QC2GDP QCX000128 120.00 1
QC2HDP QCX000129 120.00 1
QC2IDP QCX000130 120.00 1
QC2JDP QCX000131 120.00 1
QC2KDP QCX000132 140.00 1
QC2LDP QCX000133 140.00 1
QC2MDP QCX000134 140.00 1
QC2NDP QCX000135 140.00 1
QC2QDP QCX000136 140.00 1
QC2RDP QCX000137 140.00 1
QC2SDP QCX000138 140.00 1
QC2TDP QCX000139 140.00 1
QC2UDP QCX000140 140.00 1
QC2VDP QCX000141 140.00 1
QC2XDP QCX000142 140.00 1
Logic Printed Circuit Board w / E2PROM ALL QCX000143 650.00 1
Power Supply PCB ALL QCX000144 360.00 1
Current Transformer QC2F,G,H,I,J,K QCX000147 40.00 1
QC2L,M,N,Q,R,S QCX000148 120.00 1
QC2T,U,V,X QCX000149 95.00 1
MOV (with terminals and insulators) QC2F,G,H,I,J,K,L,M QCX000150 18.00 2/ph
QC2N,Q,R,S QCX000151 10.00 2/ph
QC2T,U,V,X QCX000152 70.00 2/ph
Terminal Strip (Logic PCB) All, 12-point QCX000153 16.00 1
Terminal Strip (Control Power Input to ASTAT) All, 5-point QCX000154 10.00 1
Terminal Strip for Fans QC2J-S 4-point QCX000155 7.20 ➀ 1
DIN Rail Terminals (QC2T,U,V,X) Endplate QCX000156 7.00 1
Terminal Point QCX000157 8.00 1
Insulator Panel QCX000158 7.00 1
Fuses on Power Supply Board – F2, ALL, 500mA QCX000159 3.00 1
Bussman Type GMC, 250 Vac F1, ALL, 2A QCX000160 3.00 1
Ribbon Cable, Top - Logic to Power Supply ALL QCX000161 5.00 1
Ribbon Cable, Bottom - Logic to Protection Board ALL QCX000162 6.00 1
Thermostat QC2J,K,L,M QCX000163 10.00 1
QC2N,Q,R,S,T,U,V,X QCX000164 14.00 1
Plastic Cover-ASTAT Plus ALL QCX000165 30.00 1
Fans QC2J,K,L,M QCX000166 79.00 1
QC2N,Q,R,S,T QCX000167 200.00 1
QC2U,V,X QCX000168 280.00 1
➀ List Price, GO-10G5
