PMC 16 Owner’s Manual 37
The PMC16 monitor mixer consists of the following four pages:
METERS PAGE
Preset1
I
O
1
48k
MIXER
LEVELS
EFFECT
LEVELS PAN
R
L
This is the first page visible on the
PMC16’s LCD display after boot up.
The Meters page allows you to see
the input level meters for all 16
input channels. The Meters page can
be accessed by pressing the
button until the Meters page is
displayed.
LEvELS PAGE
Preset1
I
O
1
48k
MIXER
LEVELS
EFFECT
LEVELS PAN
R
L
The Levels page allows you to adjust
each channel’s level. The Levels
page can be accessed by pressing
the button. It can also be
accessed by pressing any
SELECT> button from the Meters
page.
