3. BACk Button
This button navigates back one page when navigating menus. This button also
navigates back to the Meters page when pressed multiple times (depending upon
how deep you are nested within a menu).
4. Function Buttons
•
WIZARD Button–Pressing this button allows access to the PMC16 Setup Wizard
and Setup Menus for initially configuring the PMC16.
•
GROUP Button–Toggles the Group function on and off.
•
PRESET Button–Pressing this button allows for the storing or recalling of a
preset.
•
LEvEL Button–Enters the Level page for adjusting each channel’s level.
•
PAN Button–Enters the Pan page for adjusting each channel’s pan setting.
•
EFFECTS Button–Enters the Effects page for adjusting each channel’s effect
send level.
5. REvERB knob
This control allows for quick adjustment of the reverb’s return level, which adjusts
the overall reverb level.
6. LOW knob
This control allows for quick adjustment of the low band shelving filter. This control
affects all outputs and is used to control the low-end frequencies of the mix.
