dbx PMC16 User Manual
Page 18
PMC
16
Owner’s Manual
12
5. DSC Input Port
This port allows for future expansion of the PMC16’s feature set.
6. USB Port
This Mini USB port is used for updating the PMC16’s firmware.
7. 1/4” Outputs
Connect these balanced outputs to any balanced or unbalanced line level device,
such as an in-ear transmitter or recording device.
8. xLR Outputs
Connect these balanced outputs to an amplifier or powered wedge monitor.
9. 1/4” Headphone Output
Connect this output to headphones which have a 1/4” headphone plug.
10. 1/8” Headphone Output
Connect this output to headphones which have a 1/8” mini headphone plug.
