7. HIGH knob
This control allows for quick adjustment of the high band shelving filter. This
control affects all outputs and is used to control the high-end frequencies of the
mix.
8. MASTER knob
This control allows for quick adjustment of the master output level. This control
affects all outputs and is pre-limiter.
9. Master Level Meter
This 4-segment LED meter displays the output signal level. The four LEDs represent
-30 dBu, 0 dBu, +10 dBu, and +17 dBu (3 dB below the clip point).
10. Channel Monitor Buttons
•
CLEAR Button–Used to quickly clear all muted or soloed channels.
•
SOLO Button–Used to solo channels or channel groups.
•
MUTE Button–Used to mute channels or channel groups.
11. Scribble Strip
Use a non-permanent marker on this strip to label each channel.
12. Channel Select Buttons (1-16)
Allows for the selection of channels or channel groups for editing levels, pans,
effect sends, mutes, or solos. Dual LEDs on each button indicate channel selection
(top LED=green), solo state (bottom LED=amber), and mute state (bottom
LED=red).
