Setup Menu Options

Many of the Setup menus contain parameters which are automatically set after running

and completing the Setup Wizard. These menus allow the system engineer to make manual

adjustments to the configuration and set the global parameters which dictate how the

PMC16 operates.
CHANNEL NAMES

This menu allows you to name each input channel. Names can be edited manually or

selected from a list. To manually name a channel, use the

encoder to select the

channel then follow the on-screen instructions. When finished, scroll to “Next” then press

the

encoder.

BLULINK CHANNEL ROUTING

This menu allows the system engineer to route the desired BLU link audio channels

to each of the PMC16’s inputs. Any available BLU link channel on the network can be

assigned to any of the PMC16’s inputs. Each PMC16 on the network is independently

assignable, allowing for unique combinations of channel assignments with each PMC16.

Note:

BLU link channels 1-256 are available at 48 kHz and channels 1-128 are available

at 96 kHz.
STEREO LINKS

This menu allows for linking of adjacent channels (i.e. 1&2, 3&4, 5&6, 7&8, etc.).

Linking channels works well for instruments which contain a stereo signal and

are traditionally panned hard left and right, such as a drum machine or keyboard.

Note:

When channels are stereo linked, the channels’ pan behavior becomes a spread
