the lcd diSplay
Introduction To The Meters Page
The Meters page is the first page displayed on the LCD display after boot up and is
considered the “Home Page” of the PMC16. This page displays input level meters for all 16
input channels, offers details about which preset is currently loaded, and shows BLU link
cable connection status, BLU link network sample rate, and BLU link clock sync status.
Preset1
I
O
1
48k
2
3
4
5
6
1
