40
5.4.2 The UPS status menu
By pressing on the menu of “UPS status”, the display would
enter the next UPS status menu tree.
The content of UPS status menu tree is same as the default UPS
status summary menu.
By pressing >1s, the display would return the last main menu
tree.
The detail information about “UPS status”, please see Fig5-14
5.4.3 The event log menu
By pressing on the menu of “Event log”, the display would
enter the next event menu tree.
All the previous events, alarm and fault have been recorded here.
The information includes the illustration, the event code, and the
precise time of UPS when the event happened. By press or
<1s, all the events could be displayed one by one.
The max number of record is 50, when the number is larger than 50,
the latest will replace the previous.
By pressing >1s, the display would return the last main menu
tree.
