Getting Started for I-7000 Series Modules
Date: Jan-08, 2002 Version 1.02 page: 4
Connect the first module as in Figure 1-1-1. (If needed, replace the I-7012
module with your own and follow the diagram.) Please do not connect more
than one module at a time.
Install the 7000 Utility software from the included CD. Please refer to
chapter 2 of “ The 7000 Utility User’s Manual ”.
Run the 7000 Utility software to search for the user’s modules.
It will automatically start searching when users run the 7000 Utility . Please
click the icon to stop it. Refer to Figure 1-1-2.
Figure 1-1-2. Stop searching.
Click the menu item “ COM Port ” to select the COM port number you are
connecting to. Select the baud rate “ 9600 ” and click the “ OK ” button. Refer to
Figure 1-1-3.
Figure 1-1-3. Selecting the COM port and Baud Rate.
