Getting Started for I-7000 Series Modules
Date: Jan-08, 2002 Version 1.02 page: 18
2.5.4 Invoking the Module Configuration Settings
In order to see the configuration settings of a module, please follow
these steps:
•
Move the mouse cursor onto the desired module in the information
window.
•
Double click the left mouse button to reveal the module configuration
setting.
•
After double clicking, a configuration setting window pops up. Adjust
the configuration settings according to the user’s demand.
For example, in order to configure the I-7012 ; double click the 7012
from the list as shown in Figure 2-5-4. Then, a window titled “ Setting
Configuration for 7012D” pops up as shown in Figure 2-5-5.
Figure 2-5-4. Showing the configuration settings for the I-7012 module.
