13
3. RUNNING SERVICE WINDOW
3. Running service window
This window is not displayed in server systems.
☞ Number of devices – Total number of monitored devices.
☞ Status – Current status of service:
• 0 – Start of service, it’s carried out the basic initializations and read the Stats table.
• 1 – Waiting for the start of the first monitoring round (it’s possible to start with a few
seconds delay
– parameter start delay in SNMPMOON.ini).
• 2 – Initial start of each round.
• 3 – Waiting for responses from individual devices and broadcasting of other ques-
tions.
• 4 – Waiting for an answer of remaining devices (all devices have been addressed).
• 5 – Idle state before the next round.
• 100 – Error during reading Devices table or number of devices is zero.
• 101 – Error during the first reading Stats table.
☞ Next monitor – Time to start next monitoring round.
☞ TCPStat – State of establishing a TCP communication with the parent web application.
The core acts as a TCP server.
• 1 – Initialization state after service start.
• 12 – The successful assignment of the communication port (65031) on which it’s
waiting for the request for a connection from the client.
• 2 – Connection with the client is successfully established.
Figure 16: Running Service Window
