[ Module specs: ]
• Dimensions : 108mm x 72mm x 35mm (H x W x D)
• Operating temperature : -25 to 75ºC (-13 to 167ºF);
• Storage temperature : -40 to 80ºC (-40 to 176ºF);
• Humidity : 5 to 95%, non-condensing;

• LEDs : PWR LED for power

RUN LED for communication

ERR LED for error

[ Software Utility Tool / API Library: ]
• Provide CAN bus user-defined baud rate / acceptance filter

configuration

• Easily transmit / receive CAN messages for testing and display the

time-stamp of each received CAN message.

• Provide saving the CAN message as “TXT” file for data log.

• Provide sending CAN message by using the internal timer of module

for high precision transmission.

• Check / Reset module status remotely and get current CAN bus

message flow.

• Users can develop own program by API library quickly and easily.

[ Application: ]
• Factory Automation;

• Building Automation;

• Home Automation;

• Control system;

• Monitor system;

• Vehicle Automation;
