3.2 Verify Driver Installation:
This section will show how to verify whether the driver of I-7565-H1/H2
was properly installed. If the driver is installed successfully, then there will
be a “Virtual COM Port” assigned by Windows. Please follow the below
steps to check it.
Click “Start” Æ “Settings” Æ “Control Panel” and then double click on
the “System” icon. Once the “System Properties” screen displayed, click
on ” Hardware” tab and then click on the “Device Manager” button.
Double-click on Ports (COM & LPT) item. If the device driver was
correctly installed, users can find the “ICPDAS I-7565-H1 USB2CAN” or
“ICPDAS I-7565-H2 USB2CAN” device listing and the “Virtual COM Port”
number that Windows has assigned to the device is COM3 like Figure 3-6.
Figure 3-6: Virtual COM Port Number
