1.1 Features
• RoHS Design
• Fully compliant with USB 1.1/2.0 (Full Speed)
• Fully compatible with the ISO 11898-2 standard
• Support both CAN2.0A and CAN2.0B
• No external power supply (powered by USB)
• Integrated with one or two CAN bus interface
• Programmable CAN bus baud rate from 5Kbps to 1Mbps or user-
defined baud rate
• Support CAN bus acceptance filter configuration
• Timestamp of CAN message with at least ±1ms precision
• Support firmware update via USB
• Provide utility tool for users module setting and CAN bus
communication testing conveniently
• Provide API library for user program development
• Provide PWR / RUN / ERR indication LED
• Built-in jumper to select 120 ohm terminal resister
• Max data flow for CAN channel: 3000 fps ( depends on users’ PC
hardware performance )
• The CAN buffer is 256 data frames for I-7565-H1 and 128 data frames
in each CAN port for I-7565-H2.
• Watchdog inside
• Driver supported for Windows 2000/XP and WinCE (available soon)
1.2 Specifications
[ USB specs: ]
• Input port : USB (USB Type B)
• Compatibility : USB 1.1 and 2.0 standard
• Driver Supported : Windows 2000/XP and WinCE (available soon)
[ CAN specs: ]
• CAN interface connector:
I-7565-H1 : 9-pin D-sub male
I-7565-H2 : 10-pin terminal-block
• CAN Baud Rate : 5K ~ 1Mbps or User-defined baud rate
• Isolation Voltage : 3000Vrms on the CAN side
I-7565-H1/H2 High Speed USB/CAN Converter User’s Manual (Ver 1.1, Nov/2009) ------------- 5
