Table 3: Cable selection
Bus speed Cable type
Cable
Resistance/m
Terminator Bus Length
50k bit/s
at 1000m 0.75~0.8mm2
18AWG
70 mOhm
150~300
Ohm
600~1000m
100k bit/s
at 500m 0.5~0.6 mm2
20AWG
< 60 mOhm
150~300
Ohm
300~600m
500k bit/s
at 100m 0.34~0.6mm2
22AWG, 20AWG
< 40 mOhm 127 Ohm 40~300m
1000k bit/s
at 40m 0.25~0.34mm2
23AWG, 22AWG
< 40 mOhm 124 Ohm 0~40m
Note: The AWG means a standard method used to measure wire. The
numbering system works backwards from what people would think, the
thicker (heavier) the wire, the lower the number. For example: a 24AWG
wire is thicker/heavier than a 26AWG wire.
I-7565-H1/H2 High Speed USB/CAN Converter User’s Manual (Ver 1.1, Nov/2009) ------------- 16
