Wireless Link Failure Output

Zlinx Radio modems offer a source (PNP)transistor output
when the wireless signal strength drops below a critical level
(link failure or miss packets)

40 mA max current

Note: In order for the RSSI LED to continuously indicate the signal strength, set the
RP command (RSSI PWM timer) to FF.
