Refer to the „AT Command Mode‟ section for more information regarding the AT
Command Mode Sequence.
CC (Command Sequence
Character) Command
The CC command is used to
set/read the ASCII character
used between guard times of
the AT Command Mode
Sequence (BT + CC + AT).
This sequence enters the
module into AT Command
Mode so that data entering the module (from the host) is recognized as commands
instead of payload.
Refer to the „AT Command Mode‟ section for more information regarding the AT
Command Mode Sequence.
CD (GPO2 Configuration)
Command
Command is used to
select/read the behavior of the
GPO2 line (pin 3).
AT Command: ATCC
Binary Command: 0x13 (19 decimal)
Parameter Range: 0x20 - 0x7F
Default Parameter Value: 0x2B (ASCII “+”)
Number of bytes returned: 1
Related Commands: AT (Guard Time After), BT
(Guard Time Before)
AT Command: ATCD
Binary Command: 0x28 (40 decimal)
Parameter Range: 0 - 8 (standard rates)
Parameter
Configuration
0
RX LED
1
Default High
2
Default Low
3
(reserved)
4
RX LED (valid
address only)
Default Parameter Value: 2
Number of bytes returned: 1
