Power Consumption 5.0W max
Dimensions 1.2W x 3.3D x 4.7H
Environmental Intended for indoor use only
Operating
Temperature
-40 to 85ºC (-40 to 185ºF)
Storage Temperature -40 to 85ºC (-40 to 185ºF)
Operating Humidity 10 to 90% non-condensing
Enclosure Rating
Rating IP30
Mounting DIN rail mount, 35mm
LED Status
Front Panel LED Status
Power Red = On
OFF = No Power
RSSI (Signal Strength) Green = Strong
Yellow = OK
Red = Weak
OFF = No Signal
Wireless Data Green = Blink on with data
Note: In order for the RSSI LED to continuously indicate the
signal strength, set the RP command (RSSI PWM Timer) to
FF.
Wiring (Copper Wire Only)
Size / Type 28 to16 AWG / SOLID COPPER
Temperature Rating 105 °C (221 °F) Minimum
Terminal Torque 0.2 Nm (Newton-meters)
Certifications
FCC FCC Part 15 Class B
CE CISPR (EN55022) Class B
EN61000-6-1 Generic Standards for Residential,
Commercial, & Light Industrial
EN61000-4-2 ESD
EN61000-4-3 RFI
EN61000-4-4 EFT
EN61000-4-5 Surge
EN61000-4-6 CI
EN61000-4-8 Power Frequency Magnetic
EN61000-4-11 Voltage Dips & Interruptions
UL UL, cUL, Class 1 Div 2
RoHS directive (lead
free)
Yes
