Specifications
RF Properties
Physical Standard Proprietary radio
Range up to 3000 feet indoor or 14 miles outdoor
Frequency 900MHz
Transmit Power 1W (selectable)
Software Zlinx Radio Modem
Support Windows 2000, 2003 Server, XP, and Vista
Features AT Command
Terminal emulation
RSSI signal range test
Modem emulation
Antenna Options External Reverse Polarity SMA male jack connector, omni
directional (included with product)
Radio Address Defaulted at factory, set by software otherwise
Serial settings
Baud 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200,
230400
Data bit 7, 8
Parity None, even, odd, mark, space
Stop bit 1, 2
RS-232
Connector DB9F DCE
Lines TX, RX, RTS, CTS, DTR, RI, GND
Connector Removable terminal block
Lines TX, RX, GND
RS-422
Connector Removable terminal block
Lines 2 or 4 wire
– TX+, TX-, RX+, RX-, GND (2 or 4 wire
dipswitch selectable)
Termination 120 Ohm Dipswitch selectable
RS-485
Connector Removable terminal block
Lines 2 or 4 wire with SD control – TX+, TX-, RX+, RX-, GND (2 or
4 wire dipswitch selectable)
SD control Bit wise
Termination 120 Ohm Dipswitch selectable
Transistor link failure No wireless signal or RSSI LED off
Connector Removable terminal block with RS-422/485
Output type Open collector, dry contact, 40mA
Power Supply
Connector Removable terminal block
Input Voltage 10 –48VDC, 18-30VAC
