Introduction
Easy to install, up to 14 mile range No wires, no
cables! Zlinx radio modems get your
data moving farther, easier, and at less cost than
running cable. Plug-n-play, Modbus compatible,
signal strength indicator, space saving DIN rail
mounting. Heavy-duty, wide temperature design
handles most industrial power configurations and
tough indoor/outdoor environments.
Package Contents
Radio Modem
Antenna
Software CD
Manual on CD
Will require separate 18-30VAC or 10-48VDC Power Supply
ZP9D-115RM-LR = 5.0W max
Model # Frequency Radio
Power
RF Data Rate
ZP9D-115RM-LR 900MHz Configurable
1 mW to 1W Configurable 9600
bps or 115Kbps
