Command Descriptions
Commands in this section are listed alphabetically. Command categories are
designated between the "< >" symbols that follow each command title. By default,
Zlinx Radio Modems expect numerical values in hexadecimal since the default value
of the CF (Number Base) Parameter is '1'. Hexadecimal values are designated by the
"0x" prefix and decimal values by the "d" suffix.
%V (Board Voltage) Command
%V Command is
used to read the current voltage
of the module circuit board.
Sample Output:
5.02 V (when ATCF = 0)
5051F (when ATCF = 1) *
5.02 (when ATCF = 2)
* When CF = 1 (default), a hex integer is shown that is equal to (voltage * 65536d).
AM (Auto-set MY) Command
AM
Command is used to
automatically set the MY (Source Address)
parameter from the factory-set serial number of the module. The address is formed
with bits 29, 28 and 13-0 of the serial number (in that order). The resulting value is
displayed as a result of this command.
AP (API Enable) Command
The AP
command is used to enable the
module to operate using the
framebased API operation.
AT Command: AT%V
Binary Command: 0x3B (59 decimal)
Parameter Range (read-only): 0x2CCCA -
0x5BFFA (2.80 - 5.75 decimal)
Number of bytes returned: 4
AT Command: ATAM
Binary Command: 0x40 (64 decimal)
AT Command: ATAP
Parameter Range: 0 - 2
Parameter Configuration
0
API Disabled
(Transparent
Operation)
1
API enabled (w/out
escaped characters)
2
API enabled (with
escaped characters)
Default Parameter Value:0
Number of Bytes Returned:1
Minimum Firmware Version Required: 2.x20
