Command Reference Table
Zlinx Commands
(Zlinx Radio Modems expect numerical values in hexadecimal.
Hexadecimal values are designated by a “0x” prefix. Decimal equivalents
are designated by a “d” suffix.)
AT _
Command Binary _
Command
AT
Command
Name
Parameter
Range Command _
Category # Bytes
Returned Factory
Default
%V 0x3B (59d)
Board
Voltage
0x2CCCA -
0x5BFFA
[read-only]
Diagnostics 4 --
AM 0x40 (64d) Auto-set MY --
Networking &
Security
-- --
AP v2.x20* -- API Enable 0 - 2
Serial
Interfacing
1 0
AT 0x05 (5d)
Guard Time
After
2 - (ATST-
3)
[x 100
msec]
Command Mode
Options
2
0x0A
(10d)
BD 0x15 (21d)
Interface
Data Rate
0 - 8
(standard
rates)
0x39 -
0x1C9C38
(non-
standard
rates)
Serial
Interfacing
4 3
BR 0x39 (57d)
RF Data
Rate
0 - 1 RF Interfacing 1 1
BT 0x04 (4d)
Guard Time
Before
0 - 0xFFFF
[x 100
msec]
Command Mode
Options
2
0x0A
(10d)
CC 0x13 (19d)
Command
Sequence
Character
0x20 - 0x7F
Command Mode
Options
1
0x2B
["+"]
(43d)
CD 0x28 (40d)
GPO2
Configuratio
n
0 - 4
Serial
Interfacing
1 2
CF --
Number
Base
0 - 2
Command Mode
Options
1 1
CN 0x09 (9d)
Exit
Command
Mode
--
Command Mode
Options
-- --
CS 0x1F (31d)
GPO1
Configuratio
n
0 - 4
Serial
Interfacing
1 0
CT 0x06 (6d)
Command
Mode
Timeout
2 - 0xFFFF
[x 100 ms] Command Mode
Options
2
0xC8
(200d)
DB 0x36 (54d)
Received
Signal
Strength
0x6E - 0x28
[read-only]
Diagnostics 2 --
DT 0x00 (0d)
Destination
Address
0 - 0xFFFF
Networking &
Security
2 0
E0 0x0A (10d) Echo Off --
Command Mode
Options
-- --
