MY (Source Address)
Command
MY command is used to set/read
the Source Address of the RF
module.
NB (Parity) Command
command is used to select/read
the parity settings of the RF
module for UART
communications.
PB (Polling Begin Address)
Command
command is used to set/read the
module‟s Polling Begin Address
– the first address polled Polling
Mode is enabled.
Polling Operations: The „Polling
Base‟ (MD = 3) cycles through a
sequential range of addresses,
polling each „Polling Remote‟
(MD = 4). The base then waits for a response & proceeds to the next „Polling
Remote‟. Each „Polling Remote‟ responds by sending the data from the Data In buffer
following the RB & RO parameters. When there is no eligible data to send, the „Polling
Remote‟ will not respond. The „Polling Base‟ will move to the next address in the
polling sequence after a short delay.
AT Command: ATMY
Binary Command: 0x2A (42 decimal)
Parameter Range: 0 - 0xFFFF
Default Parameter Value: 0xFFFF (Disabled -
DT (Destination Address) parameter serves as
both source and destination address.)
Number of bytes returned: 2
Related Commands: DT (Destination Address),
HP (Hopping Channel), ID (Modem VID), MK
(Address Mask)
AT
Command:
ATNB
Binary Command: 0x23 (35 decimal)
Parameter
Range:
0 - 4
Parameter
Configuration
0
8-bit (no parity or 7-bit
(any parity)
1
8-bit even
2
8-bit odd
3
8-bit mark
4
8-bit space
Default Parameter Value:
0
Number of bytes returned: 1
AT Command: ATPB
Binary Command: 0x45 (69 decimal)
Parameter Range: 0 - 0xFFFF
Default Parameter Value: 0
Number of bytes returned: 2
Minimum Firmware Version Required: 2.x20
Related Commands: MD (RF Mode), PE
(Polling End Address), PD (Minimum Polling
Delay)
