I-7000 DIO Manual Rev:B1.2
2.3 #AABBDD
Description : Digital Output
Command : #AABBDD[CHK](cr)
#
delimiter character
AA address of reading module(00 to FF)
BBDD output command and parameter
For output multi-channel, the BB = 00, 0A or 0B the se-
lect which output group, and the DD is the output value.
For output single-channel, the BB = 1c, Ac or Bc where c
is the selected channel, and the DD must be 00 to clear
output and 01 to set output.
t u p t u O l e n n a h C -i tl u M r o f r e t e m a r a P
t u p t u O
sl e n n a h C
D D B B A A # d n a m m o c r o f D D
A 0 / 0 0 = B B B 0 = B B
D 2 4 / 2 4 0 7 -I 3 1 F F o t 0 0 ) 7 - 0 ( O D F 1 o t 0 0 ) 2 1 - 8 ( O D
D 3 4 / 3 4 0 7 -I 6 1 F F o t 0 0 ) 7 - 0 ( O D F F o t 0 0 ) 5 1 - 8 ( O D
D 4 4 / 4 4 0 7 -I 8 F F o t 0 0 ) 8 - 1 ( O D A N A N
D 0 5 / 0 5 0 7 -I 8 F F o t 0 0 ) 7 - 0 ( O D A N A N
D 0 6 / 0 6 0 7 -I 4 F 0 o t 0 0 ) 4 - 1 ( L R A N A N
s 3 6 0 7 -I 1 * 3 7 0 o t 0 0 ) 3 - 1 ( L R A N A N
s 5 6 0 7 -I 2 * 5 F 1 o t 0 0 ) 5 - 1 ( L R A N A N
D 6 6 / 6 6 0 7 -I 7 F 7 o t 0 0 ) 7 - 1 ( L R A N A N
D 7 6 / 7 6 0 7 -I 7 F 7 o t 0 0 ) 7 - 1 ( L R A N A N
1 * D B 3 6 / B 3 6 / D A 3 6 / A 3 6 / D 3 6 / 3 6 0 7 -I : e d u l c n i s 3 6 0 7 -I
2 * D B 5 6 / B 5 6 / D A 5 6 / A 5 6 / D 5 6 / 5 6 0 7 -I : e d u l c n i s 5 6 0 7 -I
