MAX1329/MAX1330
12-/16-Bit DASs with ADC, DACs, DPIOs, APIOs,
Reference, Voltage Monitors, and Temp Sensor
______________________________________________________________________________________ 67
DACA
OUTA
FBA
REFADC
REFDAC
REFADJ 2.5V
REF
A
V = 0.5, 0.82, 1
REFDAC
1.25V
2.50V
A V = 0.5, 0.82, 1
DSWA
1 μF
0.01 μF
1 μF
MAX1329
DACB
REFDAC
I
B
I
A R
A
OUTB
FBB
DSWB
R B WE
RE
CE
SNO1
SNC1
SCM1
IN1-
OSW1
OUT1
R 1
OA1
IN1+
SPDT1
Figure 29. Three-Electrode Potentiostat Software-Switchable Single- or Dual-Channel Connection
