MAX1329/MAX1330
12-/16-Bit DASs with ADC, DACs, DPIOs, APIOs,
Reference, Voltage Monitors, and Temp Sensor
54 ______________________________________________________________________________________
Table 22. Voltage Monitor 2 and Charge-Pump Control Bit Configuration
VM2CP2 VM2CP1 VM2CP0 CHARGE-PUMP STATE BYPASS SWITCH STATE
VM2 STATE
(THRESHOLD VOLTAGE)
0 0 0 Off Open Off
0 0 1 On (3V) Open On (2.7V)
0 1 0 On (4V) Open On (3.8V)
0 1 1 On (5V) Open On (4.5V)
1 0 0 Off Closed Off
1 0 1 Off Open On (2.7V)
1 1 0 Off Open On (3.6V)
1 1 1 Off Open On (4.5V)
Table 23. Charge-Pump Clock Divider Bit
Configuration
CPDIV1 CPDIV0 CHARGE-PUMP CLOCK DIVIDER
0 0 Divide by 32
0 1 Divide by 64
1 0 Divide by 128
1 1 Divide by 256
