DS3150
17 of 22
3. AC CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS*
Voltage Range on Any Lead with Respect to V
SS
(except V
DD
) -0.3V to 5.5V
Supply Voltage Range (V
DD
) with Respect to V
SS
-0.3V to 3.63V
Operating Temperature Range -40 ° C to +85 ° C
Storage Temperature Range -55 ° C to +125 ° C
Soldering Temperature Range See J-STD-020A specification
* This is a stress rating only and functional operation of the device at these or any other conditions
beyond those indicated in the operation sections of this specification is not implied. Exposure to
absolute maximum rating conditions for extended periods of time can affect reliability.
Note:
The typical values listed below are not production tested.
RECOMMENDED DC OPERATING CONDITIONS (-40
°
C to +85
°
C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Logic 1 V
IH
2.4 5.5 V
Logic 0 V
IL
-0.3 0.8 V
Supply (V
DD
) V
DD
3.135 3.465 V
DC CHARACTERISTICS (-40
°
C to +85
°
C; V
DD
= 3.3V
±
5%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Supply Current (V
DD
= 3.465V) I
DD
75 90 mA 1
Power Down Current
(V
DD
= 3.465V)
I
PD
45 mA 2
Lead Capacitance C
IO
7 pF
Input Leakage I
IL
-10 +10 µA 3
Input Leakage (w/ pullups or float) IILP -500 +500 µA 3
Output Current (2.4V) I
OH
-4.0 mA
Output Current (0.4V) I
OL
+4.0 mA
NOTES:
1) TCLK = MCLK = 44.736MHz and Tx+ and Tx- driving all ones into a 75 Ω load/other inputs at V
DD
or grounded/other outputs left open-circuited.
2) MCLK = 44.736MHz and TTS* = 0/other inputs at V
DD
or grounded/other outputs left open-circuited.
3) 0V < V
IN
< V
DD.
4) Outputs in three-state.
