21
T89C5115
4128A–8051–04/02
Data Memory
The T89C5115 provides data memory access in two different spaces:
The internal space mapped in three separate segments:
• the lower 128 bytes RAM segment.
• the upper 128 bytes RAM segment.
• the expanded 256 bytes RAM segment (ERAM).
A fourth internal segment is available but dedicated to Special Function Registers,
SFRs, (addresses 80h to FFh) accessible by direct addressing mode.
Figure 7 shows the internal data memory spaces organization.
Figure 7. Internal Memory – RAM
Internal Space
Lower 128 Bytes RAM The lower 128 bytes of RAM (see Figure 7) are accessible from address 00h to 7Fh
using direct or indirect addressing modes. The lowest 32 bytes are grouped into 4 banks
of 8 registers (R0 to R7). Two bits RS0 and RS1 in PSW register (see Figure 16) select
which bank is in use according to Table . This allows more efficient use of code space,
since register instructions are shorter than instructions that use direct addressing, and
can be used for context switching in interrupt service routines.
The next 16 bytes above the register banks form a block of bit-addressable memory
space. The C51 instruction set includes a wide selection of single-bit instructions, and
the 128 bits in this area can be directly addressed by these instructions. The bit
addresses in this area are 00h to 7Fh.
256 bytes
Upper
128 bytes
Internal RAM
Lower
128 bytes
Internal RAM
Special
Function
Registers
80h 80h
00h
FFh FFh
00h
FFh
direct addressing
addressing
7Fh
Internal ERAM
direct or indirect
indirect addressing
Table 15. Register Bank Selection
RS1 RS0 Description
0 0 Register bank 0 from 00h to 07h
0 1 Register bank 0 from 08h to 0Fh
1 0 Register bank 0 from 10h to 17h
1 1 Register bank 0 from 18h to 1Fh
