Cobalt Digital COMPASS 9220 Bidirectional ASI_MPTS Gateway User Manual
Page 31
31
9220-UM V1.1
The indicators can have the following values:
•
OK: The IP Input is receiving a valid transport stream.
•
No Lock: The IP Input is not receiving a valid transport stream. If there is a
connection to this input, Dashboard™ Card State and the Status LED will be red.
•
Disabled: The IP Input has been disabled (by setting Enable to No).
