Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1204 User Manual
Page 53
ARROW ON HUB OF INSTALLED
BACKSTOP MUST MATCH
DIRECTION OF DESIRED
SHAFT ROTATION
BACKSTOP SHAFT
COVER GASKET
BACKSTOP
SHAFT COVER
SPACER (IF APPLICABLE)
OUTER RACE
INNER RACE
RETAINING
RING
BACKSTOP
FASTENERS
BACKSTOP
KEY
REDUCER WITH
BACKSTOP INSTALLED
REDUCER WITHOUT
BACKSTOP INSTALLED
Figure 7 – Backstop Assembly
48 PNEG-1204 Enclosed Belt Conveyors
