Figure 2 – Parts Identification
TYPICAL COOLING FAN ASSEMBLY
FOR REDUCER SIZES 6 THROUGH 12
TYPICAL COOLING FAN ASSEMBLY
FOR REDUCER SIZES 4 AND 5
8
7
1
4
2
3
5
6
9
2
Table 2 – Cooling Fan Part Numbers
Description
Ref.
Number
Quantity
TA4207
TA5215
TA6307
TA7315
TA8407
TA9415
TA10507
TA12608
Cooling Fan Assembly
-----
1
904106
905106
906106
907106
907106
909106
910106
912106
Fan Guard Plate Assy.
1
1
-----
-----
906519
906519
906519
909519
909519
912519
Fan Blade
2
1
904517
905517
906517
907517
907517
909517
910517
910517
Fan Guard Cover
3
1
-----
-----
906521
906521
906521
909521
909521
909521
Mounting Bolt
4
4
-----
-----
411294
411294
411294
411294
411294
411294
Fan Set Screw
5
2
-----
-----
400086
400086
400086
400086
400086
400086
Cover Bolt
6
4
-----
-----
411390
411390
411390
411390
411390
411390
Lockwasher
7
4
-----
-----
419010
419010
419010
419010
419010
419010
Hex Nut
8
4
-----
-----
407085
407085
407085
407085
407085
407085
Taper Bushing Assy.
9
1
117162
117092
-----
-----
-----
-----
-----
-----
Assembly includes parts listed below marked
Set screws are included with taper bushing assembly.
