PNEG-1204 Enclosed Belt Conveyors
Belting Assembly
SPLICING THE BELT
1. Support belt ends with wood plank. Nail
Flexco Template in position with belt ends
tight against lugs.
2. Spray template holes with Flexco Silicone
Lubricant. Punch or bore bolt holes. Remove
template.
1
2
2
Splice protector design may vary due to type of
conveyor. I.E. - Reversible conveyors and
conveyors with low-profile head discharges do
not have splice protectors with tails (flippers).
