Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1204 User Manual
Page 19
14
PNEG-1204 Enclosed Belt Conveyors
Motor Assembly
MOTOR AND SHAFT TORQUE ARM II INSTALLATION
Motor
Allow sufficient distance between bushing and
bearing to remove bushing assembly bolts.
Keep as close
as possible
Head Section
Driven
Pulley
Belt
Guard
Belt
Guard
Bracket
V-Belt
Drive
Pulley
Hex Nut
Motor Adjustment Plate
Jackscrew
Motor Mount Base Plate
Head
Section
Intermediate
Inspection
Section
Motor
Drive Pulley
V-Belt
Hood
Torque Arm
Turnbuckle Assembly
Driven
Pulley
Reducer
Drive
NOTE: Belt Guards Not
Shown for Clarity.
Torque Arm
Bracket
