IP-2 wire system technical guide
Index Device Name IP Adress
32 Default GL 192.168.0.254 FFFF
31 Guard Station 2(G3LV) 192.168.0.253
30 Guard Station 3(IP-Agent) 192.168.0.243
Index Device Name IP Adress
09 Default GL 192.168.0.254 FFFF
10 Guard Station 2(G3LV) 192.168.0.253
11 Guard Station 3(IP-Agent) 192.168.0.243
Press Write to Device to download the setup to DT-IPC(192.168.0.22) after finished
Press Write to Device to download the setup to DT-IPC(192.168.0.23) after finished
Edit Button Call Map table:
C Block(192.168.0.23)
General Description: 4 DS and 8 IM, use DMR11 and DT598 model
IM Description:
1) User codes of IM are from 01 to 08
2) [09] in Namelist to call Default GL, [10] to call Guard Station 2(192.168.0.253), [11] to
call Guard Station 3(192.168.0.243)
DS Description:
1) 3 DMR11 and 1 DT598, ID code: 00,01,02,03
2) Press 09 to call Default GL, 10 to call Guard Station 2(192.168.0.253), 11 to call Guard
Station 3(192.168.0.243)
Call Table Setup: A Block -> right Click then select Management -> Select Call Table ->
Select Button Call Table -> Select View & Edit
Edit Button Call Map table:
D Block(192.168.0.24)
General Description: 1 DMR11 + EP24 and 16 IM
IM Description:
1) User codes of IM are from 09 to 24
2) [00] in Namelist to call Default GL, [31] to call Guard Station 2(192.168.0.253), [30] to
call Guard Station 3(192.168.0.243)
-95-
