IP-2 wire system technical guide
1. Project Property
Project Name: TEST001
Project Descriptions: Totally 4 blocks, 2 Common Entrances, 2 G3LV, 2 IP-Agent
Project Remark: 2 wire system
IP seg: 192.168.0.X
2. IP Node Config
Config the IP Node which will be used in this project
IP Enable Model Device Name
192.168.0.20 yes CM-IPC Network Camera
192.168.0.21 yes DT-IPC_DS A Block
192.168.0.22 yes DT-IPC_DS B Block
192.168.0.23 yes DT-IPC_DS C Block
192.168.0.24 yes DT-IPC_DS D Block
192.168.0.25 yes DT-IPC_CDS Common Door Station 1
192.168.0.26 yes DT-IPC_CDS Common Door Station 2
192.168.0.240 yes C5-IPC Guard Unit Camera
192.168.0.243 yes PC Guard Station 3
192.168.0.244 yes PC Guard Station 4
192.168.0.253 yes GL-IPC Guard Station 2
192.168.0.254 yes GL-IPC Guard Station 1
-90-
Appendix 1
Prepare a IP network in DT system
All the setup is set in IP-Device software beside door station ID code setting, Monitor user
code setting and DIP setting of DT-IPC.
