2.2.4 Installation Setup Instructions
DIP Switch Status(Defaults are OFF)
a) DIP switches settings:
ON(1)
=
OFF(0)
=
ON
ON
S201 switches settings:
Total 6 bits switches.Bit-6 is used to set the video impedance matches.
Functions of bit1 to bit 5 are reserved.
1 2 3 4 5
6
ON
1 2 3 4 5
6
ON
SW201 switches settings:
Bit state
Setting
Bit state
Setting
Set to high
impedance
Match video
impedance
Item
Bit state
Descriptions
Bit-1
/ /
Reserved
Bit-2
Villa application mode
Apartment application mode
Bit-3
Set to "on",press Direct Call Guard Unit on monitor to
call switchboard
Set to "off",press Direct Call Guard Unit on monitor to
call local Guard monitor
Bit-4
Set as common door station
Set as door station
1 2
3
4
ON
1 2
3
4
ON
1
2
3 4
ON
1
2
3 4
ON
1 2 3
4
ON
1 2 3
4
ON
-24-
IP-2 wire system technical guide
