IP-2 wire system technical guide
A Block(192.168.0.21)
General Description:
1) 2DS and 4 IM, use DT592 model
2) 1st button in DT592 call all IM. 2nd button call default Guard Unit(Default GL).
3) User Namelist in IM to call Guard Station
IM Description:
1) Totally 4 IM in this block whose user codes are from 00 to 03
2) [16] in Namelist to call Default GL, [17] to call Guard Station 2(192.168.0.253), [18] to
call Guard Station 3(192.168.0.243)
DS Description:
1) 2 DS, their ID codes : 00 and 01
2) 1st buttton to call all IM, 2nd button to call Default GL
Call Table Setup: A Block -> right Click then select Management -> Select Call Table ->
Select Button Call Table -> Select View & Edit
Edit Button Call Map table:
Index Device Name IP Adress
16 Default GL 192.168.0.254 FFFF
17 Guard Station 2(G3LV) 192.168.0.253
18 Guard Station 3(IP-Agent) 192.168.0.243
Press Write to Device to download the setup to DT-IPC(192.168.0.21) after finished
B Block(192.168.0.22)
General Description: 2 DS and 8 IM, use DMR18 model
IM Description:
1) User codes of 8 IM are from 01 to 08
2) [00] in Namelist to call Default GL, [31] to call Guard Station 2(192.168.0.253), [30] to
call Guard Station 3(192.168.0.243)
DS Description:
1) 2 DMR18, ID code: 00 and 01
2) Input 32 to call Default GL, 31 to call Guard Station 2(192.168.0.253), 30 to call Guard
Station 3(192.168.0.243)
Call Table Setup: A Block -> right Click then select Management -> Select Call Table ->
Select Button Call Table -> Select View & Edit
-94-
