Name and Fuction of each Item in Monitor Viewer
Item Name Description
1 Device List Consists of 4 parts: GL&PC, DS&CDS, Monitor&Camera
2 Call List Call info record
3 Alarm Alarm and events record
4 Unlock 1 * Unlock the first latch of the entrance
5 Unlock 2 * Unlock the second latch of the entrance
6 Capture Capture a picture of the selected video window
7 Record Performs/Stop Recording the selected video window
8 Digital Keypad Open digital keypad for operation
9 Exit Exit monitoring
10 Maximum Maximize the monitoring screen
11 Aspect Ratio Select an aspect ratio and a number of split screen
12 Reserved Reserved
13 Reserved Reserved
14 Monitor Screen Displays the monitor viewer screen
15 Adjust Window Button Displays or hides the menu window
16 Video Screen Displays monitoring video
