For example, in Benchmark Project, see the table, IP Nodes can be configured like the
following picture
IP Device
192.168.0.20 Camera
192.168.0.20 to 192.168.0.24 Door Station
192.168.0.25 to 192.168.0.26 Common Door Station
192.168.0.254 and 192.168.0.253 Guard Unit( IP-G21 )
192.168.0.243 and 192.168.0.244 PC Station( IP-Agent )
IP Node Config:
If all the device has been installed in the project, you can click the Scan & Check button to
search if the selected IP Nodes are online. If not installed yet, click Save button to write the
info to the database. Then main interface will show the devices like the following picture.
