2.2.6 IP Address Setup
1. General Rules for IP Adress Setup
2. IP Address Setup by IP8210 Config Software
For constructing a DEDICATED LAN for IP system, all network devices must be specified
different IP Address.
* Network device model includes DT-IPC, CM-IPC, IP-G21 and PC Station.We will just
state device short for network device in the following statement.
* All network device can be detected by IP8210 config and IP-Device, but only DT-IPC,
CM-IPC & IP-G21 can be set by the two softwares. PC Station is set by Windows IP setup
All the devices must be in the same IP Segment.(Assume that using the segment:
192.168.0.X in this manual )
* 192.168.0.1 is used as a network gateway. Devices can’t be set to this address
* All devices must be set a unique IP address & MAC address
* If more than one device have the same IP address, only one of them can be available
by IP8210 config or IP-Device software
* If PC & the device to be set have the same IP, the device can’t be detected by IP8210
config or IP-Device software in this PC.
* Here are the table for range of device IP address
Range: Device:
192.168.0. 2 – 192.168.0. 240 DT-IPC, CM-IPC
192.168.0.241– 192.168.0.246 PC Station(IP-Agent)
192.168.0.247 – 192.168.0.254 Guard Station(IP-G21)
For new devices, IP address of devices are initialized to the same address, so it’s
recommended that IP address of devices is set one by one. It’s easily fulfilled via IP8210
Config software.
