IP-2 wire system technical guide
All the above requirement can be met by 2-Easy intercom system.
Apartment Device
Network Device
2. Count Project Points
Building No. of floors
for 1 building
No. of
flats on
each floor
Total flats IM
Distributor Power
supply Gateway DS
A Block /
/
1
4
1
1
1
1
B Block 8
2
16
16
4
1
1
1
C Block 6
4
24
24
7
1
1
2
Total
41
44
12
3
3
4
Series
Name
Model
Qty
Unit
Remark
1
Door Station
DMR18
3
PC
For B & C blocks
2
Door Station
DT592
1
PC
For A block
3
Monitor
DT27SD
44
PC
with memory function
4
Distributor
DT-DBC4S
12
PC
One out of them connects
multi-door stations in C
Block
5
Power Supply
PS5-24V
3
PC
1 power supply feeds one
building
6
Gateway
DT-IPC
3
PC
Series
Name
Model
Qty
Unit
Remark
1
Guard Station
IP-G21
1
PC
Total 2 Switchboards
2
PC with PC
Station
/
1
PC
3
Common Door
Station
DMR18
1
PC
1
4
Power Supply
PS5-24V 2
PC
One PS5 feeds one G21 and the
other feeds common door station
5
Gateway
DT-IPC
1
PC
For Common Door Station
6
Network Switch /
/
PC
The quantity of switch depends on
project installation
3. Select Device Model & Make Device List
