INSTALLATION GUIDE
EA10 SERIES
Start End Size R/W Name Type Units SF Contents Description
40407 40407 1 R Sensor 4 Unit ID uint16 N/A Sensor Unit ID:
ID Description
0 No unit detected or unit is not communicating. Module status LED is red.
1 8 channel, 20 A current sensor. Module status LED is green
40408 40408 1 R Address uint16 N/A Sensor address on the EA10’s internal bus
40409 40409 1 R OS Version uint16 N/A Sensor firmware version
40410 40411 2 R Product Version ASCII N/A Sensor product revision
40412 40416 5 R Serial Number uint16 N/A 10 digit Sensor serial number
40417 40417 1 R C_SunSpec_DID uint16 Device ID Start of next device (Null DID = 0xFFFF)
40418 40418 1 R C_SunSpec_Length uint16 Device Length Device model block size (null length = 0x0000)
ACCESSORIES
Model Description
AV02 DIN rail stop clip
EA10X01 Spare parts: end cap, o-rings, and connectors
